ESD PEEK slot side panel

Core Features

Static Dissipative Properties: Specifically formulated with carbon-filled additives to provide essential Electrostatic Discharge (ESD) protection, preventing static buildup that could damage sensitive semiconductor wafers or electronic components.
Precision Machined Slot Geometry: Engineered via high-precision CNC machining to create exact slot widths and depths, ensuring uniform spacing and secure retention for substrates.
Extreme Thermal Endurance: Maintains absolute dimensional stability and structural rigidity in continuous operating environments up to 250°C (482°F).
High-Purity & Low Outgassing: Manufactured to ensure a metallic-ion-free environment with minimal outgassing, satisfying the strict requirements for ultra-high vacuum (UHV) and clean-room applications.
Superior Chemical Immunity: Completely resistant to aggressive industrial solvents, etching acids, and organic bases, ensuring the panel does not warp or degrade during wet-processing cycles.

Primary Use Cases

Semiconductor Wafer Carriers: Primary structural side panels for custom wafer racks used in wet-etching and high-temperature cleaning where ESD safety is mandatory.
Electronics Assembly Fixtures: Slotted frameworks for holding sensitive circuit boards during high-heat soldering or testing phases to prevent electrostatic failure.
Clean-Room Material Handling: Precision-slotted panels for organizing and transporting delicate components in environments where particulate generation must be zero.
Aerospace Instrumentation Racks: Lightweight, high-strength side panels for modular electronic enclosures where vibration resistance and thermal insulation are required.
Laboratory Diagnostic Modules: Slotted guide panels for multi-port switching valves or sample trays requiring both chemical purity and static dissipation.

Frequently Asked Questions

How does ESD PEEK differ from standard Natural PEEK?

Natural PEEK is an electrical insulator. ESD PEEK is blended with carbon-based fillers to allow for controlled dissipation of static electricity, making it safe for handling sensitive electronic components that would otherwise be damaged by static discharge.

Can Kriloha machine variable slot widths or non-standard pitches?

Absolutely. Because we use precision CNC machining, we are not limited by mold dimensions. We can customize slot width, depth, and the distance between slots (pitch) to match your proprietary substrates exactly.

Is the ESD property affected by high temperatures?

No. PEEK maintains its mechanical and dissipative properties up to its continuous service temperature of 250°C, ensuring consistent static protection even during high-heat processing.

Is this material safe for use in harsh etching acids?

Yes. PEEK is chemically inert to almost all organic solvents, acids, and bases. It is the industry standard for semiconductor wet-processing because it does not react with aggressive etching chemicals.

Can you integrate mounting holes or locking tabs into the panel design?

Yes. As a customization specialist, we can process intricate mounting features, countersunk holes, or proprietary locking mechanisms directly into the PEEK panel based on your CAD specifications.
